WaveNet H16E164MYL2-500 (1) CAT6E 600 Hz U TP Cable + (1) 16AWG 4C Audio Cable
WaveNetCall 817-864-1089 for availability
(No reviews yet)
Write a Review
WaveNet
WaveNet H16E164MYL2-500 (1) CAT6E 600 Hz U TP Cable + (1) 16AWG 4C Audio Cable
- Features
- Combination: CAT6E 600MHZ UTP + 16AWG 4C Audio Cable
- CAT6 UTP - Physical Characteristics
- Conductor Material: Bare Solid Copper
- 23AWG
- Insulation Material: HDPE
- Jacket Material: Flame retardent PVC
- .57mm Conductor Diameter
- .23mm Insulation Diameter
- 6.5mm Outer Diameter
- Insulation Colors: White insulation with stripe (White/Blue, White/Green, White/Brown, White/Orange)
- 16AWG 4C Audio - Physical Characteristics
- Conductor Material: Copper
- 16AWG
- Polyethylene/Polypropylene Insulation Material
- .303mm Average Thicness
- 1.98mm Conductor Diameter
- Number of Conductors: 4
- Insulation colors: Red/ White/ Yellow/ Blue
- Ley Length: Twist
- PVC Jacket Material
- .406mm Average Thickness
- 5.4mm Overall Cable Dia.
- 16AWG 4C Audio - Electrical Characteristics
- Temperature Rating: -20 ~ +60°C
- Operating Voltage Rating: 300 Volts
- Capacitance Between Conductor @ 1 KHz: 23.5 Pf/M Nom.
- DC Resistance (Ω/km) per Conductor @ 20°C: 13.9 Ohms Nom.
