comCABLES CN-F3GHZ-FKY-WHT

comCABLES CN-F3GHZ-FKY-WHT F-Type Module 3GHz

ComCables
SKU:
CN-F3GHZ-FKY-WHT
$2.30

Call (817)864-1089 for Availability

(No reviews yet)
Current Stock:
Description
  • Dimensions
    • Depth – 30.00 mm | 1.181 in
    • Height – 16.50 mm | 0.650 in
    • Width – 16.50 mm | 0.650 in
  • Construction Materials
    • Housing Brass W/ Nickel Plating
    • Seizing Pin 360º Beryllium Bronze W/ Gold Plating
    • Insulator Nylon Dielectric | White
    • Plastic Material ABS 94V-0
    • Nut Material Iron Plated W/ Nickel Over Copper
  • General Specifications
    • F-Type Female to Female
  • Environmental Specifications
    • Flammability Rating UL 94 V-0
    • Safety Standard cUL | UL
    • Relative Humidity Up to 93%, Non-Condensing
    • Operating Temperature -40ºC to + 65ºC ( -40 °F to + 149 °F)
  • Mechanical Characteristics
    • Seizing Pin (Accepts Center Conductors) Range (0.64 mm - 1.07 mm Diameter) Holding Force >160 Grams (Initial)
    • >120 Grams (After Insertion)
    • Housing Shall Support 2.2Kg Force (Min) Applied to Insulator
    • From Either Direction
  • Electrical Characteristics
    • Frequency Range DC -3HGz
    • Insertion Loss < 0.2 dB
    • Return Loss > 30dB
    • Contact Resistance < 4 Milliohms
